Features

Plain and basic design
Can measure outside and inside diameter (OD and ID), depth, and steps.
The small vernier face angle (14⁰) provides easy reading.
Different reading scales on vernier (metric/inch and inch models only)
Clamping screw atop the slider.
Carbide-tipped jaw type calipers are also available.

Specifications (Metric)

Range Order No. Depth Bar Remarks
0-150mm 530-102 ǿ1.9mm rod -
0-150mm 530-101 Blade -
0-150mm 530-320 Blade Carbide-tipped jaws for outside measurement
0-150mm 530-335 Blade Carbide-tipped jaws for outside and inside measurement
0-150mm 530-319 Blade Clamping screw below the slider
0-150mm 530-122* Blade High accuracy model ±0.03mm
0-200mm 530-108 Blade -
0-200mm 530-321 Blade Carbide-tipped jaws for outside measurement
0-200mm 530-123* Blade High accuracy model ±0.03mm
0-200mm 530-109 Blade -
0-200mm 530-322 Blade Carbide-tipped jaws for outside measurement
0-200mm 530-124* Blade High accuracy model ±0.04mm
0-600mm 530-501- - -
0-1000mm 530-502 - -

Metric/Inch

Range Order No. Depth Bar Inch Graduation Remarks
0-150mm 530-104 Blade 1/128* -
0-150mm 530-316 Blade 1/128* Clamping screw below the slider
0-150mm 530-125 Blade 1/128* -
0-150mm 530-312* Blade .001* High accuracy model ±0.03mm
0-200mm 530-114 Blade 1/128* -
0-200mm 530-118* Blade .001* High accuracy model ±0.03mm
0-300mm 530-115 Blade 1/128* -
0-300mm 530-119* Blade .001* High accuracy model ±0.04mm
