Features

Specifications

Max Workpiece dimensions (W/D/H)  810mm x 700mm x 215mm

Wire Diameter                                      0.1mm - 0.3mm

Table Dimensions                                640mm x 540mm

Machining Travel (X/Y/Z)                     400mm x 300mm x 220mm

Machining Travel (U/V)                        ±60mm x ±60mm

Max Taper Angle                                 15º with 200mm workpiece thinkness

Max Workpiece weight                       1100lbs.

Machine weight                                   3960lbs

For more information, visit the Mitsubishi Electric website.
