Series 215
Mitutoyo’s Granite Comparator Stands are basic building-blocks for the assembly of special-purpose, précising measuring equipment. By mounting precision measuring instruments such as Digmatic indicators, Mu-Checker Cartridge Heads, and Linear Gages onto the stands, it is possible to handle all manner of measuring applications. The rigid granite base is free from burrs, pileups, rust, and deterioration over time.
Specifications
| Order No. | Granite base size (WxDxH) | Column travel | Stem hole | Remarks |
|---|---|---|---|---|
| 215-151 | 150x200x50mm | 260mm | ǿ8mm | With fine adjustment of 1mm range |
| 215-153 | 200x250x80mm | 250mm | ǿ8mm | With fine adjustment of 1mm range |
| 215-154 | 300x250x80mm | 300mm | ǿ8mm | With fine adjustment of 1mm range |
| 215-156 | 300x250x80mm | 300mm | ǿ8mm, ǿ20mm | With fine adjustment over the entire travel |
